Have you ever wondered how the hardness of different metals affects their performance in engineering applications? In this blog post, we’ll explore the Vickers hardness standards for various materials, helping you understand their suitability for your projects. Get ready to enhance your knowledge and make informed decisions in your mechanical engineering endeavors!
Stainless steel grades exhibit varying levels of hardness, a critical property that influences their machinability, wear resistance, and overall performance in diverse applications. The following table provides a comprehensive overview of the typical hardness values for common stainless steel grades.
Material | Hardness Standard HV (Vickers) | Material | Hardness Standard HV (Vickers) |
SUS301-CSP-1/2H | 310–370 | C2680-1/4H | 75–125 |
SUS301-CSP-3/4H | 370–430 | C2680-1/2H | 85–145 |
SUS301-CSP-H | 430–490 | C2680-H | 105–175 |
SUS301-CSP-EH | >490 | C2680-EH | >145 |
SUS304-CSP-1/2H | 250–310 | C5159-1/4H | 100–160 |
SUS304-CSP-3/4H | 310–370 | C5159-1/2H | 150-205 |
SUS304-CSP-H | >370 | C5159-H | 180–230 |
C5159-EH | 200 | ||
SUS631-CSP-0 | <200 | ||
SUS631-CSP-1/2H | 350–400 | C2600-1/4H | 75–125 |
SUS631-CSP-3/4H | 400–450 | C2600-1/2H | 85–145 |
SUS631-CSP-H | >450 | C2600-H | 105–175 |
C2600-EH | ≥145 | ||
C2801-1/4H | 85-145 | ||
C2801-1/2H | 105-160 | C2720-1/4H | 75–125 |
C2801-H | ≥130 | C2720-1/2H | 85–145 |
C2720-H | ≥105 | ||
C4250-1/4H | 80–140 | ||
C4250-1/2H | 110–170 | C5111-1/4H | 80–150 |
C4250-3/4H | 120–180 | C5111-12H | 120–180 |
C4250-H | 140–200 | C5111-H | 150–200 |
C4250-EH | ≥150 | C5111-EH | 170 |
C5102-1/4H | 90–160 | C5212-1/4H | 100–160 |
C5102-1/2H | 130–190 | C5212-1/2H | 150–205 |
C5102-H | 170–220 | C5212-H | 180–235 |
C5102-EH | 190 | C5212-EH | 210 |
C7351(C7451)-1/2H | 105–155 | C7541-1/2H | 110–170 |
C7541-H | 135 | ||
C7521-1/2H | 120–180 | ||
C7521-H | 150 | C1201/1220/1221-1/4H | 55–100 |
C1201/1220/1221-1/2H | 75–120 | ||
C1020(C1100)-1/4H | 55–100 | C1201/1220/1221-H | ≥80 |
C1020(C1100)-1/2H | 75–120 | ||
C1020(C1100)-H | ≥80 |
